| 1 |
Overall layout dimension |
280m × 18m × 7.5m |
| 2 |
Designed annual output |
120,000 units/year |
| 3 |
Production tact time |
90–120 seconds/vehicle |
| 4 |
Conveyor line speed |
0.15–0.3 m/min adjustable |
| 5 |
Number of working stations |
120 main stations |
| 6 |
Body-in-white conveying mode |
Skid conveyor + friction drive |
| 7 |
Powertrain assembly precision |
±0.1 mm positioning accuracy |
| 8 |
Bolt tightening control system |
Torque control ±3% error |
| 9 |
Air supply pressure |
0.6–0.8 MPa |
| 10 |
Workshop temperature control |
18–26 ℃ |
| 11 |
Workshop relative humidity |
45%–65% RH |
| 12 |
Noise level at operation area |
≤75 dB(A) |
| 13 |
Total installed power |
3,200 kW |
| 14 |
Max. vehicle weight capacity |
3,500 kg |
| 15 |
Automation rate |
65%–75% |
